FLRY-A
Haoqiang
Temperature range : -40°C~ +105°C
Executive Standard: DIN 72551-5/1991
Conductor : 0.22-2.5mm² tinned copper or bare copper
Insulator: PVC
Color: red, black, yellow, green, blue, white, brown, gray, two-color
Application: Used for automobile connecting line. With oil resistance, heat resistance, cold resistance, flame resistance, wear resistance and other characteristics
| Conductor | Insulator | Max.Cond. Resistance at 20°C (Ω/km) | |||
| AWG | Construction (No./mm) | Diameter (mm) | Insulator Thickness (mm) | Outer Diameter (mm) | |
| 0.22 | 7/0.21 | 0.63 | 0.26 | 1.15 | 86.5 |
| 0.35 | 7/0.26 | 0.78 | 0.24 | 1.25 | 54.5 |
| 0.5 | 19/0.19 | 0.95 | 0.28 | 1.50 | 38.2 |
| 0.75 | 19/0.23 | 1.15 | 0.33 | 1.80 | 25.4 |
| 1 | 19/0.26 | 1.30 | 0.35 | 2.00 | 19.1 |
| 1.5 | 19/0.32 | 1.60 | 0.35 | 2.30 | 13.0 |
| 2.5 | 19/0.41 | 2.05 | 0.43 | 2.90 | 7.8 |
Temperature range : -40°C~ +105°C
Executive Standard: DIN 72551-5/1991
Conductor : 0.22-2.5mm² tinned copper or bare copper
Insulator: PVC
Color: red, black, yellow, green, blue, white, brown, gray, two-color
Application: Used for automobile connecting line. With oil resistance, heat resistance, cold resistance, flame resistance, wear resistance and other characteristics
| Conductor | Insulator | Max.Cond. Resistance at 20°C (Ω/km) | |||
| AWG | Construction (No./mm) | Diameter (mm) | Insulator Thickness (mm) | Outer Diameter (mm) | |
| 0.22 | 7/0.21 | 0.63 | 0.26 | 1.15 | 86.5 |
| 0.35 | 7/0.26 | 0.78 | 0.24 | 1.25 | 54.5 |
| 0.5 | 19/0.19 | 0.95 | 0.28 | 1.50 | 38.2 |
| 0.75 | 19/0.23 | 1.15 | 0.33 | 1.80 | 25.4 |
| 1 | 19/0.26 | 1.30 | 0.35 | 2.00 | 19.1 |
| 1.5 | 19/0.32 | 1.60 | 0.35 | 2.30 | 13.0 |
| 2.5 | 19/0.41 | 2.05 | 0.43 | 2.90 | 7.8 |
